GL-DY143 698~960/1710~2690MHz 3dBi IPEX Patch Antenna

Product Overview

GL-DY143 is a patch antenna prepared for embedded 3G, 4G, 5G, LTE, IoT and router devices requiring compact internal installation. The confirmed table includes Frequency Range: 698~960/1710~2690MHz; Gain: 3dBi; Polarization: Linear; VSWR: <3.0; Nominal Impedance: 50Ω.

This page is built from the model-specific local product document and image set. The product can be quoted or sampled from confirmed product data; request the latest formal drawing if the project requires additional documentation.

Key Features

• GL-DY143 Patch Antenna for embedded 3G, 4G, 5G, LTE, IoT and router devices requiring compact internal installation
• Operating band: 698~960/1710~2690MHz
• Gain: 3dBi
• Polarization: Linear
• VSWR: <3.0
• Connector: IPEX
• Cable: RF1.13 or others
• Installation: Method | Embedded

Technical Specifications

Mechanical and Installation Notes

Use the listed mounting method: Method | Embedded. Match the RF interface to IPEX. Review operating limits against -40℃~+85℃.

Applications and Industries

GL-DY143 can be considered for embedded 3G, 4G, 5G, LTE, IoT and router devices requiring compact internal installation. Match the operating band, gain, connector, mechanical size and installation method to the radio, enclosure and coverage target before release.

Resources

• Engineering file set: 1 supporting local document(s) used to prepare this listing
• Formal downloadable document: not attached in this upload package

Engineering Selection Notes

Before release or sampling, review the product against the target radio, receiver, enclosure, ground plane, cable route and installation surface. If a listed value does not match the project requirement, request a matching connector, cable length, bracket, color, label or packaging option.

Sampling and Customization Support

For sample support, provide SKU GL-DY143, target frequency, connector type, cable length, mounting space, application environment, expected quantity and any packaging requirements. Rftech can confirm the closest standard model or a custom variant.

FAQ

What operating band does GL-DY143 support?

GL-DY143 is listed with 698~960/1710~2690MHz. Check this band against the module, network band or receiver requirement before sampling.

What connector details are available for GL-DY143?

Connector: IPEX. Cable: RF1.13 or others. Confirm variants before ordering.

How is GL-DY143 installed?

Installation: Method | Embedded.

Can GL-DY143 be quoted from this listing?

Yes. This listing uses confirmed model-specific product data and images; request the latest formal document when procurement approval requires it.
