Frequency700-2700
Gain3
PolarizationVertical
VSWR<=2.0
Nominal Impedance50
RF Product · Patch Antenna
Patch Antenna, 700-2700, 3 GL-DY146
SKUGL-DY146
GL-DY146 is a patch antenna for embedded 3G, 4G, 5G, LTE, IoT and router devices requiring compact internal installation. Key specifications include frequency 700-2700, gain 3, connector IPEX. Suitable for RF projects that require verified model-specific specifications and configurable sampling support.
700-270040.4x15.4x0.13
Need a different connector, cable configuration or frequency? Send the SKU and project requirements.
Commercial informationData revision V1 · 10 September 2026 · valid through 10 September 2029
MOQ10 pieces
SamplesFree sample available
Standard lead time7 days
CustomizationConnector and frequency
ProductionMass production
Volume pricing is negotiable. Custom-order MOQ is confirmed against the project specification.
Documented product data
Technical specifications
Values below come from the fields currently recorded for this model.SKUGL-DY146
Frequency700-2700
Dimensions40.4x15.4x0.1
Gain3
PolarizationVertical
VSWR<=2.0
Nominal Impedance50
Connector TypeIPEX
CableRG1.13-150mm
Operating Temperature-30~60
Humidity5~95
CategoryPatch Antenna
Verified product record
Product details
Available fields are grouped by engineering purpose without filling unsupported values.Dimensions40.4x15.4x0.1
Connector TypeIPEX
CableRG1.13-150mm
Operating Temperature-30~60
Humidity5~95
SKUGL-DY146
CategoryPatch Antenna
