806-3800MHz N-K Lpda Antenna for RF Systems GL-DY8038V11
SKUGL-DY8038V11
GL-DY8038V11 is a vertically polarized LPDA with an N-K connection and three separate operating frequency groups.
Need a different connector, cable configuration or frequency? Send the SKU and project requirements.
Volume pricing is negotiable. Custom-order MOQ is confirmed against the project specification.
Documented product data
Technical specifications
Values below come from the fields currently recorded for this model.
Product details
GL-DY8038V11 is an LPDA option for a directional installation spanning several stated frequency groups. Check the working channels against each group individually, rather than selecting it only by the lowest and highest frequency entries. Its vertical polarization should also match the intended link arrangement.
The N-K connection determines the equipment-side feeder termination, while the enclosure drawing should be used to check the available mounting space. The three gain entries belong to different frequency groups and should not be treated as one uniform value. If the installation requires a specific pointing tolerance or coverage sector, obtain the model-specific radiation pattern before choosing the mounting position. Frequency coverage alone does not define that sector.
