Terminal Antenna 400-480 MHz GL401A

SKUGL401A

Choose GL401A when a 200 mm antenna can be accommodated; compare GL401F if the available clearance calls for a much shorter whip.

400-480 MHz200 mm400-480

Documented product data

Technical specifications

Values below come from the fields currently recorded for this model.
SKUGL401A
Frequency400-480 MHz
Dimensions200 mm
Frequency-MHz400-480
Bandwidth-MHz16
Gain-dBi2.15
VSWR≤2
Nominal Impedance-Ω50
PolarizationVertical
Maximum Power-W30
Length-mm200
Weight-g30
ConnectorBNC or TNC(Matches with TNC connector,add T after model)
RemarksWhip shape
CategoryTerminal Antenna

Engineering selection guide

Product details

How this model fits the documented RF, interface and installation requirements.

Choosing this model

GL401A selection guide

Choose GL401A when a 200 mm antenna can be accommodated; compare GL401F if the available clearance calls for a much shorter whip. The listed gain difference is small, so it should not outweigh a physical fit or connector requirement.

GL401A and GL401F share the same listed operating range, bandwidth and power limit, but differ substantially in length. Specify BNC or TNC when ordering; the TNC configuration uses a T suffix after the model number.
