Terminal Antenna 450-500 MHz GL450UI

SKUGL450UI

GL450UI is the shortest model in the GL450UI, GL450UIA and GL450UIB group.

450-500 MHz75 mm450-500

Documented product data

Technical specifications

Values below come from the fields currently recorded for this model.
SKUGL450UI
Frequency450-500 MHz
Dimensions75 mm
Frequency-MHz450-500
Bandwidth-MHz20
Gain-dBi2
VSWR≤2
Nominal Impedance-Ω50
PolarizationVertical
Maximum Power-W50
Length-mm75
Weight-g50
ConnectorSMA male
CategoryTerminal Antenna

Engineering selection guide

Product details

How this model fits the documented RF, interface and installation requirements.

Choosing this model

GL450UI selection guide

GL450UI is the shortest model in the GL450UI, GL450UIA and GL450UIB group. Their listed RF specifications match, so available space, weight and connector configuration are more useful selection criteria than gain.

GL450UIB has the same listed weight but is longer; GL450UIA is longer and heavier. The base GL450UI lists SMA male, while the other two explicitly allow connector customization. Choose the model by those differences rather than treating a suffix as an RF performance upgrade.
