GLDISH6983800 dish hyperbolic antenna with aluminum alloy reflector

RF Product Parabolic Dish Antenna

GLDISH6983800 698-3800 MHz Dish Hyperbolic Antenna

SKU GLDISH6983800

Dual-band dish hyperbolic antenna with 9/22 dBi gain for 698-960 and 1710-3800 MHz.

SKU GLDISH6983800

Frequency 698-960 / 1710-3800 MHz

Dimensions 0.6 m diameter

Model TA-PWD7038-9/22S

Bandwidth 262 / 2090 MHz

Gain 9 / 22 dBi

Request Quote for This Model Datasheet

Need custom cable length, connector, or frequency support? Send us the SKU and project requirements.

SKU	GLDISH6983800
Frequency	698-960 / 1710-3800 MHz
Dimensions	0.6 m diameter
Model	TA-PWD7038-9/22S
Bandwidth	262 / 2090 MHz
Gain	9 / 22 dBi
Beamwidth	H 16 deg / E 12 deg
F/B ratio	>= 25 dB
VSWR	<= 2.0
Polarization	Vertical or Horizontal
Max. power	100 W
Nominal impedance	50 ohm
Connector	N Female or customized
Antenna dimension	0.6 m
Weight	4 kg
Material	Aluminum alloy
Rated wind velocity	60 m/s
Category	Parabolic Dish Antenna

Product overview

Dual-band dish hyperbolic antenna for 698-960 and 1710-3800 MHz with an aluminum alloy reflector.

Key specifications

Model	TA-PWD7038-9/22S
Frequency range	698-960 / 1710-3800 MHz
Bandwidth	262 / 2090 MHz
Gain	9 / 22 dBi
Beamwidth	H 16 deg / E 12 deg
F/B ratio	>= 25 dB
VSWR	<= 2.0
Polarization	Vertical or Horizontal
Max. power	100 W
Nominal impedance	50 ohm
Connector	N Female or customized
Antenna dimension	0.6 m
Weight	4 kg
Material	Aluminum alloy
Rated wind velocity	60 m/s

Selection guidance

Confirm the required band, polarization, connector, and 0.6 m antenna clearance before selecting this model.

Downloads

Download the GLDISH6983800 datasheet

FAQ

What frequency range does GLDISH6983800 cover?

698-960 / 1710-3800 MHz

What connector does GLDISH6983800 use?

N Female or customized

What are the listed dimensions?

0.6 m diameter

Request a quote for GLDISH6983800

Selection and Project Support

GLDISH6983800 698-3800 MHz Dish Hyperbolic Antenna is listed by Rftech for RF antenna and wireless connectivity projects in the Parabolic Dish Antenna category. Use the specifications, images, and notes on this page as the starting point for model review before requesting drawings, samples, or customization support.

Integration Notes

Before production, confirm the operating band, connector, cable, mounting method, available installation space, and target application environment. Rftech can help review these details against the information already shown for this product (SKU GLDISH6983800).

Customization and Documentation

For OEM or ODM projects, contact the team with your required frequency range, connector preference, cable length, mechanical limits, and expected use case. Product drawings, samples, and project-specific recommendations can be requested when the available page details are not enough for final selection.
