8 Folded Dipole Antenna 400-480 MHz GL400IIA

SKUGL400IIA

Consider GL400IIA when the higher-gain folded dipole configuration justifies a larger installation.

400-480 MHz465 cm400-480

Request a Quote Download Datasheet

Documented product data

Technical specifications

Values below come from the fields currently recorded for this model.

SKUGL400IIA

Frequency400-480 MHz

Dimensions465 cm

Frequency-MHz400-480

Bandwidth-MHz16

Gain-dBiOmni 12/Directional 15

Vertical Beamwidth-º6.5

VSWR≤1.5

Nominal Impedance-Ω50

PolarizationVertical

Maximum Power-W100

Dimensions-cm465

Weight-kg10.6

Rated Wind Velocity-m/s60

ConnectorN Female or Customization

RemarksAntenna main pole and clip code can be purchased separately;The antenna main pole and supporting pole are provided by the customer

CategoryFolded Dipole Antenna

Engineering selection guide

Product details

How this model fits the documented RF, interface and installation requirements.

Choosing this model

GL400IIA selection guide

Consider GL400IIA when the higher-gain folded dipole configuration justifies a larger installation. Its vertical beam is much narrower than GL400IA-S, so compare the elevation of the intended direction as well as the gain figure.

The size and weight trade-off is substantial: GL400IIA is listed at 465 cm and 10.6 kg, compared with 68 cm and 0.72 kg for GL400IA-S. Choose the smaller model if the mounting envelope cannot accommodate that difference. Main and supporting poles are customer-provided.
