Yagi Antenna 400-490 MHz GL400Z5WS

SKUGL400Z5WS

GL400Z5WS is the shorter, lighter Yagi choice compared with GL401D.

400-490 MHz0.7 m400-490

Documented product data

Technical specifications

Values below come from the fields currently recorded for this model.
SKUGL400Z5WS
Frequency400-490 MHz
Dimensions0.7 m
Frequency-MHz400-490
Bandwidth-MHz20
Gain-dBi9
Vertical Beamwidth-º48
Horizontal Beamwidth-º54
F/B Ratio-dB≥15
VSWR≤1.5
Nominal Impedance-Ω50
PolarizationVertical
Maximum Power-W100
Length-m0.7
Weight-kg0.6
Rated Wind Velocity-m/s60
ConnectorN Female or Customization
CategoryYagi Antenna

Engineering selection guide

Product details

How this model fits the documented RF, interface and installation requirements.

Choosing this model

GL400Z5WS selection guide

GL400Z5WS is the shorter, lighter Yagi choice compared with GL401D. Consider it when the available mounting space or antenna weight matters more than selecting the higher listed gain.

GL401D trades a longer, heavier structure for higher gain and a narrower horizontal beam. Choose between them by the installation envelope and the required pointing width, rather than assuming that two models with the same operating range are equivalent.

Current documentation

Downloads

Files shown here are linked to this exact product record.

RF Product

Discuss this model with an RF engineer

Send the required band, connector, installation limits and quantity. We will review the request against the selected model.Request a Quote
