RF Product · Fiberglass Omni Antenna
1.92-2.17GHz N-K Fiberglass Omni Antenna GL-DY1922V6
SKUGL-DY1922V6
A shorter fiberglass omnidirectional antenna with an N-K connection for the same mid-band range.
1920-2170Ф20×400Vertical
Need a different connector, cable configuration or frequency? Send the SKU and project requirements.
Commercial informationData revision V1 · 10 September 2026 · valid through 10 September 2029
MOQ10 pieces
SamplesPaid sample; fee credited toward a volume order
Standard lead time14 days
CustomizationConnector and frequency
ProductionMass production
Volume pricing is negotiable. Custom-order MOQ is confirmed against the project specification.
Documented product data
Technical specifications
Values below come from the fields currently recorded for this model.SKUGL-DY1922V6
Frequency1920-2170
DimensionsФ20×400
polarizationVertical
vswr≤2.0
impedance50
connectorN-K
temperature-40°c～60°c
CategoryFiberglass Omni Antenna
Product details
The GL-DY1922V6 keeps the fiberglass omni format and N-K feed of the longer V11 model in a shorter body. The reduced length changes the mechanical envelope while the radio band and vertical polarization remain the same. Its bottom connector determines the mating feeder.
