GLRG8X RG8X 50 Ohm Coaxial Cable (DC–3GHz)
SKU GLRG8X
Need custom cable length, connector, or frequency support? Send us the SKU and project requirements.
| SKU | GLRG8X |
|---|---|
| Frequency | DC–3GHz (VSWR ≤ 1.15) |
| Dimensions | Jacket OD 6.25±0.1mm |
| Cable Type | RG8X, 50 Ω flexible coax |
| Impedance | 50±2Ω |
| Inner Conductor | Tinned copper, 1.5±0.02mm |
| Dielectric | Foam polyethylene FPE, Ø4.0±0.1mm |
| Shield | Tinned Copper |
| Jacket | PVC, Ø6.25±0.1mm |
| Capacitance | 80±2 pF/m |
| Velocity of Propagation | 84% |
| Peak Power | 1.9 kW |
| Cutoff Frequency | 6 GHz |
| VSWR | ≤ 1.15 (DC–3GHz) |
| Operating Temperature | -40 to +85°C |
| Category | Coaxial Cables & Connectors |
The GLRG8X is a 50-ohm RG8X coaxial cable with foam polyethylene fpe dielectric and a pvc jacket at 6.25±0.1mm outer diameter. It is built for reliable RF signal transmission in antenna, wireless and instrumentation systems.
Key specifications
- Impedance: 50±2Ω
- Dielectric / jacket: Foam polyethylene FPE / PVC, 6.25±0.1mm OD
- Velocity of propagation: 84%; capacitance 80±2 pF/m
- Peak power: 1.9 kW; cutoff frequency 6 GHz
- VSWR: ≤ 1.15 from DC–3GHz
- Operating temperature: -40 to +85°C
Typical applications
- Lower-loss antenna feeder runs
- Base-station and repeater jumpers
- Outdoor antenna trunk connections
- Longer 50 Ω RF links where loss matters
Cable assemblies and connectors
GLRG8X can be terminated with N, TNC and 4.3-10 connectors for custom cable assemblies. Send us your connector pair, length and frequency band and we will build the assembly to spec.
How to choose
Match the cable to your loss budget, frequency, power and environment. For higher temperature or tighter RF stability, compare a PTFE/FEP type; for longer or higher-power runs, step up to a lower-loss family. Browse the full range on our products page or request a quote for a made-to-order assembly.
Related coaxial cables
Selection and Project Support
GLRG8X RG8X 50 Ohm Coaxial Cable (DC–3GHz) is listed by Rftech for RF antenna and wireless connectivity projects in the Coaxial Cables & Connectors category. Use the specifications, images, and notes on this page as the starting point for model review before requesting drawings, samples, or customization support.
Integration Notes
Before production, confirm the operating band, connector, cable, mounting method, available installation space, and target application environment. Rftech can help review these details against the information already shown for this product (SKU GLRG8X).
Customization and Documentation
For OEM or ODM projects, contact the team with your required frequency range, connector preference, cable length, mechanical limits, and expected use case. Product drawings, samples, and project-specific recommendations can be requested when the available page details are not enough for final selection.
